6 Circuit Switch Panel

Description

Six circuit race car switch panel with heavy duty switchgear. This includes one momentary switch for your starter, and five lighted on-off switches. The on-off switches have resettable circuit breakers instead of fuses, so if you need to get your race vehicle back on track and limp into the pits, you can let it cool off and push the button instead of having to find a fuse. Includes three 10 amp circuits for light loads and two 20 amp units for heavy loads. The switches themselves are all rated for 20 amps. Terminals accept 1/4″ spade connectors, not included. Panel is black powdercoated aluminum, light weight and corrosion resistant.

Panel measures 3″ x 7.75″, and the hole bolt pattern is 2.75″ x 7.5″.

The switches are made in Mexico, and we’re not sure where the circuit breakers come from, but they’re probably imported. The circuit breakers are splash resistant, and the switches are immersion rated. Metalworking, powder coating, and final assembly are done here in the USA.

Click HERE for installation notes.
